Lub cev muaj zog thiab kev siv:
Technical Parameters:
|
Cov khoom siv hluav taws xob |
Peb Theem AC 380V ± 10% 50HZ |
|
Qhov Chaw Siab |
0.45-0.7Mpa |
|
Rated zog |
12 kWm |
|
Cua ceev |
MAX 800 RPM |
|
Suav Qhov tseeb |
± 0.01 hli |
|
Angular Qhov tseeb |
0.1 degree |
|
Hlau Arrangement Precision |
0.01mm ib |
|
Optimum Winding Diameter |
0.1-0.5 hli |
|
Qhov siab haum |
Hauv 80mm |
|
Siv tau Outer Diameter |
17-80 hli |
|
Zuag qhia tag nrho Dimension |
1350 * 1050 * 1900 hli |
|
Tshuab hnyav |
750 KG |
Machine thiab Function Overview:
Qhov Stator koob winding tshuab (Model R4108) yog 4-chaw nres tsheb tag nrho automated internal winding tov, tshwj xeeb hauv siab -precision koob winding ntawm stators rau cov khoom siv hauv tsev (xws li, mini cua txias compressors, ntse tshuab ntxhua khaub ncaws micro- tsav) thiab muaj micromot conveyors (xws li, 14) lub cev muaj zog. Nws txhawb stator puab diameters los ntawm Φ17mm mus rau Φ80mm thiab pawg tuab txog li 80mm, nrog 4-chaw nres tsheb thaum uas tig mus ua hauj lwm synchronizing koob winding, xaim kev npaj, thiab stator loading / unloading los txiav ntau lawm voj voog rau high-volume stator manufacturing.
Raws li lub hom phiaj -tsim stator koob- hom winding ntaus ntawv, nws integrates 7 pawg ntawm imported servo motors (ib tug ywj siab tsav ib qho chaw nres tsheb) los xyuas kom meej cov hlau nozzle qhov nkag tsis tu ncua - tseem ceeb rau stator kev ua tau zoo, vim tsis sib xws koob winding yuav ua rau lub cev muaj zog overheating los yog torque txo. Lub tshuab lub thav duab yog welded los ntawm siab- lub zog square raj nrog hauv qab counterweights, txo qhov nruab nrab ntawm lub ntiajteb txawj nqus kom txo tau kev co thaum lub sij hawm siab - khiav ceev. Qhov no ntau yam koob-raws li stator winding chav tsev nta ib tug adaptable hlau nozzle flipping mechanism rau ntau haiv neeg stator core designs (xws li, sib txawv qhov suav los yog hlau core duab), tshem tawm ntau zaus cov cuab yeej hloov thaum hloov ntawm tsev neeg thiab industrial stator qauv.
Fixtures ua los ntawm cov ntaub ntawv txawv teb chaws undergo tshwj xeeb xov kom tswj clamping precision tsis khawb stator nto, thaum tus qauv kev ruaj ntseg teeb curtains raws li muaj kev ruaj ntseg rhiav kev cai. Rau cov tuam txhab tsom mus rau siab -precision, npaum stator ntau lawm rau tsev neeg thiab industrial micro- motors, stator koob winding tshuab seamlessly sib npaug 4- chaw nres tsheb throughput thiab koob winding-specific raug, sawv tawm raws li ib tug txhim khu kev qha kev xaiv rau niaj hnub motor manufacturing.
FAQ:
Q: Koj qhov warranty thiab tom qab muag yog dab tsi?
A: 1 xyoo lav rau cov khoom tseem ceeb (HMI, Lub tog raj kheej, Controller, Servo motor, Lead ntsia hlau, swb rail), peb muab kev txhawb nqa los ntawm video
hu.
Q: Koj lub sijhawm them nyiaj yog dab tsi?
A: T / T, 50% ua ntej thiab 50% tshuav nyiaj li cas ua ntej xa.
Q: Txoj kev xa khoom yog dab tsi?
A: Peb tsuas yog ua FOB Shenzhen. Ua siab zoo txheeb xyuas nrog peb pab neeg ua ntej xa koj daim ntawv xaj.
Q: Koj puas tuaj yeem txhawb nqa cov qauv kev pabcuam rau winding kuv stator?
A: Yog lawm! Txhua yam koj yuav tsum tau ua yog xa koj cov stator thiab tooj liab winding hlau rau peb pab neeg, thiab peb yuav siv cov khoom tsim nyog los cua koj stator-ces peb yuav xa cov qauv ua tiav rov qab rau koj rau kev kuaj xyuas kom muaj nuj nqis.
